EQUINOX 700 TECH SPECS
Search Modes
Park, Field, Beach
All-Metal Shortcut
Yes
Custom Search Profiles
6
User Profile Button
No
Operating Frequencies (kHz)
Multi, 4, 5, 10, 15
Noise Cancel
Auto (19 Channels)
Ground Balance
Auto, Manual, Tracking
Sensitivity
1 to 25
Target Volume
0 to 25
Threshold Level
0 to 25
Threshold Pitch
Fixed
Target Identification (TID)
119 segment notch discrimination: Ferrous: -19 to 0 I Non-ferrous: 1 to 99
Target Tones
1,2, 5, All Tones (At), Depth (dP)
Tone Break
Ferrous (T1)
Tone Pitch
Tone 1 adjustable: 0 to 25
Tone Volume
Tone 1 adjustable: 0 to 25
Recovery Speed
1 to 3
Iron Bis
0 to 3
Depth Indicator
5 Levels
Discrimination Segments
119 Segments
Pinpoint Mode
Yes
Wireless Audio
Yes
Length (approx.)
Collapsed: 61 cm (24 in) - Extended: 144 cm (56.7 in)
Weight
1.27 kg (2.8 lbs)
Display
Monochrome LCD
Display and Keypad Backlight (red)
Off, High, Low
Flashlight
On, Off
Vibration
On, Off with separate Ferrous Control
Supplied Coil
EQX11 11" Double-D coil with skid plate
Audio Output
In-built loudspeaker, Wired 3.5 mm (1/8") headphones, Wireless headphones
Supplied Headphones
Minelab ML 85 Low Latency wireless headphones
Battery
3.7V/5100 mAh Internal Lithium-lon battery
Additional Included Accessories
Getting Started Guide, Screen Protector (English), Charging Cable
Waterproof
5m (16 ft) IP68
Operating Temperature Range
-10 to +40 degrees celcius (+14 to +104 degrees fahrenheit)
Storage Temperature Range
-20 to +70 degrees celcius (-40 to +158 degrees fahrenheit)
Key Technologies
Multi-IQ
